Brother KE-430HS-03 Bartack Machine

Description Brother KE-430HS-03 Bartack Machine Superior sewing quality, usability, and reduces maintenance cost. Technical Specifications Model Brother KE-430HS-03 Lubrication type Minimum lubrication Application Medium materials Max. sewing speed 3,300sti/min Max. sewing area Max. 40x30mm Stitch length 0.05～12.7mm Feed mechanism Y-θ intermittent feed mechanism (pulse-motor driven mechanism) No. of stitches Variable (Refer to “Program List” for details on the number of stitches for sewing patterns that are already preset) Max.No. of stitches 5,000 stitches/pattern Work clamp lifter Pulse motor drive system Work clamp height / Button clamp height Max. 17mm Rotary hook Shuttle hook (double shuttle hook, optional) Digital tension Standard equipment Thread wiper Standard equipment Thread trimmer Standard equipment Thread nipper Option Data storage method Internal flash memory (Data addition is available with external memory) No. of cycle programs 30 cycle (50 programs for each cycle) No. of stored data 89 sewing patterns are set already (up to 512 patterns can be added. Total number of stitches of stored data which can be added is within 500,000*2) Motor AC servo motor 550W (Direct Drive) Weight Machine head: Approx. 58kg Operation panel: Approx. 0.5kg Control box: Approx. 7kg Power supply Single-phase 100V/200V, 3 phase 220V/380V/400V 400VA (For single-phase 100V and 3-phase 380V/400V, the trans box is require
