Brother BAS-360H-05A Pattern Sewing Machine

Description Brother BAS-360H-05A Pattern Sewing Machine Technical Specifications Model Brother BAS-360H-05A Stitch form Single needle lock stitch Max. sewing speed 2,700sti/min Max. sewing area 500x400mm Footprint 1,489mmx1,296mm Feed mechanism Intermittent feed (pulse motor drive) Stitch length 0.05-20.0mm (per 0.05mm) Max. number of stitches 100,000 stitches (per program) Max. number of programs 999 Work clamp lift amount Max. 52.5mm Height of stepping presser foot 25mm(highest needle stop position) Stepping presser foot stroke 0-10mm(per 0.1 mm) Hook Double-capacity shuttle hook Needle cooler Standard equipment Thread wiper Standard equipment Thread trimmer Standard equipment Digital tension Standard equipment Thread breakage detector Standard equipment (fiber sensor drive) Data storage media Internal flash memory (data addition is available with external memory) Motor AC servo motor 550W Weight Approx. 630kg Power Single phase 220V / 230V 3-phase 200V / 220V / 380V / 400V Apparent power/Power consumption 950VA/ 560Wh Air pressure/Consumption 0.5MPa/Needle cooler ON:1.8l/min OFF:0.2/min
